The SBC-T3.5P-250XP is a direct bolt on high output alternator for the OEM alternator on Toyota 7GR-FKS engine. It installs in the OEM mounting location and connects directly to the vehicle’s wiring harness with no modifications.
Battery Cables
The SBC-T3.5P-250XP is a direct bolt on high output alternator for the OEM alternator on Toyota 7GR-FKS engine. It installs in the OEM mounting location and connects directly to the vehicle’s wiring harness with no modifications.
- Idle Output: 186 Amps
- Max Output: 251 Amps
- Regulator: Toyota LIN
Key specifications:
- Idle Output: 186 Amps
- Max Output: 251 Amps
- Regulator: Toyota LIN
applications:
- 2004 to present Toyota Tacoma
- 2019 to present Toyota Hiace
- 2010-2020 Toyota Land Cruiser Prado
Full specifications:
- Output Voltage: 12
- Maximum Amperage: 251
- Amps @ Normal Engine Idle: 186
- Amps @ High Engine Idle: 200
- Mounting: OEM Mounting Direct Bolt-in
- Rotation: Clockwise
- Housing Material: 6061 Aircraft Grade Aluminum
- Pulley Diameter: 2.01″ (51.10 mm)
- Pulley Material: 7075 Aircraft Grade Aluminum
- Output Stud: M8 x 1.25
- Ground: Case
- Regulation: Internal
- Regulator: Toyota LIN
- Excitation: Self-excited
- Net Weight: 16 lbs (7.3 kg)
- Gross Weight: 18 lbs (8.1 kg)
