TWIN 24V 350 AMPS

Battery Cables

When upgrading from an OEM to an SBC high-output alternator, you should upgrade the positive and negative (ground) cables to handle the increased current.

Please refer to our Wire Sizing Chart for recommended gauges.

WIRE SIZING CHART

Product Categories

TWIN 24V 350 AMPS
TWIN 24V 350 AMPS - Image 2
TWIN 24V 350 AMPS - Image 3
TWIN 24V 350 AMPS - Image 4

The SBC-D24V-350 is a TWIN alternator specifically engineered for use with SBC multi-alternator packages.

Available with internal or external regulation.



  • Secondary Voltage: 24 Volts
  • Secondary Idle Output: 183 Amps
  • Secondary Max Output: 350 Amps
Add to Quote
SKU: cd0cbcc668fe-1-2-1-2-1-1-1-2-1-2-1-1-3-1-1 Category:

All SBC TWIN alternators are designed and manufactured in house using only the highest-grade materials. The compact alternator housing is precision machined from Aircraft Grade 6061 aluminum and allows the assembly of two alternators into a single housing to offer the highest idle output in the industry.



The pulleys are made from Aircraft Grade 7075 aluminum with a Type III hard anodized coating for increased strength and durability.





Key specifications:



  • Secondary Voltage: 24 Volts
  • Secondary Idle Output: 183 Amps
  • Secondary Max Output: 350 Amps



Full Specifications:



  • Output Voltage: 24
  • Maximum Amperage: 350
  • Amps @ Normal Engine Idle: 183
  • Amps @ High Engine Idle: 207
  • Mounting: TWIN
  • Rotation: Clockwise
  • Housing Material: 6061 Aircraft Grade Aluminum
  • Pulley Diameter: 2.20″ (56.00 mm)
  • Pulley Material: 7075 Aircraft Grade Aluminum
  • Ground: Case
  • Regulation: Internal or External
  • Net Weight: 37.1 lbs (16.8 kg)
  • Gross Weight: 43 lbs (19.5 kg)
